Holz Ziegel Lehm | Pilot Project Sustainable Housing Berlin

Berlin-Britz | Germany

Client
Stadt und Land Wohnbauten-Gesellschaft, Berlin
GENERAL PLANNING | ARCHITECTURE
Arge ZRS Architekten GvA mbH und Bruno Fioretti Marquez GmbH
Structural Engineering | ACOUSTIC PLANNING
ZRS Ingenieure
Landscape Design
Schönherr Landschaftsarchitekten Partm, Berlin
Technical building service
DKIPlan, Dieterich | Klose – Ingenieure für Technische Gebäudeausrüstung PartGmbB
Electrical engineering
IRG, Ingenieurgesellschaft für rationelle Gebäudetechnik mbH, Berlin
ENERGY CONSULTING | BUILDING PHYSICS | FIRE PROTECTION
ZRS Architekten
CLIMATE DESIGN, SIMULATION
Ingenieurbüro Hausladen GmbH, München
DRAINAGE PLANNING
RCL, Redeker Consult Luckenwalde Ingenieurgesellschaft mbH, Luckenwalde
GROSS FLOOR AREA
3,622 m²
LIVING AREA
2,371 m²
RESIDENTIAL UNITS
36
FLOOR AREA
2,731 m²
procurement procedure | Planning time | CONSTRUCTION TIME
2020 | since 01|2021 | since 08|2023
Funding
Senatsverwaltung für Umwelt, Mobilität, Verbraucher- und Klimaschutz DBU Deutsche Bundesstiftung Umwelt
RESEARCH
TU Berlin, Natural Building Lab | Universität Stuttgart, Institut Wohnen und Entwerfen | TU Braunschweig, Institut für Bauklimatik und Energie der Architektur
Visualisations | Plans
Arge ZRS Architekten GvA mbH und Bruno Fioretti Marquez GmbH

Against the backdrop of cost pressure and mechanisation in public housing construction the Berlin-based housing association STADT UND LAND launched a pilot project for sustainable multi-storey residential construction in 2019 which is being realised by ZRS Architekten together with Bruno Fioretti Marquez. Two new buildings, one in timber-clay and the other in brick-timber construction, demonstrate the potential of sustainable construction in public rental housing under real-life laboratory conditions. The two participating offices are contributing their many years of expertise in timber construction (ZRS) and monolithic brick construction (BFM) to the project. The aim is to reduce the use of building technology through climate-adapted design and simple but robust construction with renewable, climate-controlling building materials and thereby reducing CO2 emissions in the construction of conventional residential buildings by at least 50 %.

The two detached new buildings with pitched roofs are being built in Alt-Britz. They each have five floors without a basement. 36 eligible rental flats are planned, half of which are barrier-free. The buildings are identical in terms of floor plans and volume, but are designed with different materials and approaches. One building is being constructed purely as a timber frame structure, the second as a monolithic brick building with timber ceilings. Clay plaster is used in both buildings. The ecological balance of the two construction methods will be compared as part of the project. The buildings are designed to be as robust, simple, solid and durable as possible. The use of diffusion permeable building materials means that ventilation and air conditioning technology can be dispensed with. The planning, construction process and usage of the houses will be scientifically monitored and evaluated.
